EMZ-8TR-P 7X-45X Plain Stand Stereo Microscope System

The EMZ-8TR stereo trinocular head is a Meiji workhorse, bringing exceptional optical quality in a compact, ergonomic design. With optional 10x eyepieces, the head offers smooth, zoom magnification from 7x - 45x while retaining focus throughout the zoom range. The trinocular port beam-splitter allows simultaneous viewing from all three eyetubes to easily facilitate on-screen displays and video applications with an appropriate digital camera.

The eyetubes are set at 45-degree inclination for viewing comfort, rotate 360-degrees, and include dual dioptric adjustments. Interpupillary eye adjustment is 54mm - 75mm and working distance is 81mm. Higher magnification is available with optional eyepieces and objectives.

The EMZ-8TRD stereo trinocular head is a Meiji workhorse, bringing exceptional optical quality in a compact, ergonomic design. With optional 10x eyepieces, the head offers smooth, zoom magnification from 7x - 45x while retaining focus throughout the zoom range. The trinocular port beam-splitter allows simultaneous viewing from all three eyetubes to easily facilitate on-screen displays and video applications with an appropriate digital camera.

Solid click-stop detents offer the user a quick, easy means of returning to a known magnification setting, increasing accuracy and productivity in repeated imaging applications.

The eyetubes are set at 45-degree inclination for viewing comfort, rotate 360-degrees, and include dual dioptric adjustments. Interpupillary eye adjustment is 54mm - 75mm and working distance is 81mm. Higher magnification is available with optional eyepieces and objectives.

The EMZ-8TRU trinocular stereo head is a Meiji workhorse, bringing exceptional optical quality in a compact, ergonomic design. With optional 10x eyepieces, the head offers smooth, zoom magnification from 7x - 45x while retaining focus throughout the zoom range. The trinocular port beam-splitter allows simultaneous viewing from all three eyetubes to easily facilitate on-screen displays and video applications with an appropriate digital camera.

The head also offers near-vertical illumination, making it ideal for imaging bores, voids or holes. The eyetubes are set at 45-degree inclination for viewing comfort, rotate 360-degrees, and include dual dioptric adjustments. Interpupillary eye adjustment is 54mm - 75mm and working distance is 81mm. Higher magnification is available with optional eyepieces and objectives.

The EMZ-8TR stereo trinocular head is a Meiji workhorse, bringing exceptional optical quality in a compact, ergonomic design. With optional 10x eyepieces, the head offers smooth, zoom magnification from 7x - 45x while retaining focus throughout the zoom range. The trinocular port beam-splitter allows simultaneous viewing from all three eyetubes to easily facilitate on-screen displays and video applications with an appropriate digital camera.

The eyetubes are set at 45-degree inclination for viewing comfort, rotate 360-degrees, and include dual dioptric adjustments. Interpupillary eye adjustment is 54mm - 75mm and working distance is 81mm. Higher magnification is available with optional eyepieces and objectives.

The P is a versatile and cost-effective 20mm diameter pole stand which includes an F-size focus block and plain base. The focusing block features dual coarse focus knobs, rack and pinion gearing, a safety clutch with tension adjustment and 55mm of travel. The base base includes reversible white & black stage plate and two stage clips.

An extended working distance pole stand with 250mm pole and "F" focusing holder mounted on a comfortable, ergonomic base. The stand features an integrated coarse focusing slide block, reversible white & black stage plate and two stage clips. The base dimensions are 330mm (12.99”) wide x 280mm (11”) deep. (For use with all EM stereo bodies)

Super Widefield Eyepiece 10X (paired) stereo microscopes. (With 25mm reticle mount)

Super Widefield High Eyepoint 10x Paired Eyepieces Req'd for EMZ-5H, 8TRH, 13H Series stereo microscopes. (With 25mm reticle mount)

The new Omano 80 LED ring light offers a combination of cool, bright, shadow-free illumination with adjustable intensity control and affordable pricing. Designed to replace our 10W and 12W fluorescent ring lights, this light is an inexorable step away from fluorescent illumination in microscopy applications.

The light has an internal diameter of 60mm with adjustable retaining screws for smaller housings. An adapter is also included. For worry-free operation, the light includes auto-switching power input for use with 90V-265V power supplies.

A new well-designed 64 LED ring light joins the Omano illumination stable. It includes integrated transformers and four independent ON/OFF zones in addition to variable intensity controls for maximum flexibility. A service life greater than 100,000 hours translates into years of trouble-free, energy-saving performance. Ring fits microscopes up to 60mm diameter and includes a 48mm ring adapter.

A new well-designed 144 LED microscope ring light joins the Omano illumination stable. It includes an integrated transformer to accept 90V-265V power and four independent ON/OFF zones in addition to variable intensity controls for maximum flexibility. A service life greater than 100,000 hours translates into years of trouble-free, energy-saving performance. This microscope ring fits scopes up to 60mm in diameter and includes a 48mm ring adapter.

A microscope ring light is an excellent accessory for just about any scope. These lights are designed to be clamped or screwed on to the bottom of your scope’s nosepiece ring, fitting snugly around your objective lens, sometimes with the use of a specific adapter piece designed to work with your specific brand of scope. These ring lights can then be used to illuminate your sample from above, increasing the amount of reflected light and improving your ability to observe and interact with specific types of sample specimens that aren’t able to be illuminated from below.

Controlling a microscope ring light is done through a corded box that contains on/off and intensity settings. This allows you to specify the amount of illumination you desire. Ring lights have been traditionally made with compact fluorescent bulbs, but LED technology has quickly supplanted these older bulbs because they are cheaper to operate, don’t require any warm-up time, pose no hazards from broken bulbs, and can emit almost identical color temperatures while also illuminating either the entire stage or selected portions of it.

Summary

The Meiji MA961 40 LED illumination system fits most stereo microscopes and allows true color reproduction of the specimen at all brightness levels without the yellow hue of halogen. As an upgrade from the MA964, the MA961 also features on/off control of the four circular quadrants. Durable LED technology delivers 10,000 hours of bright daylight quality, flicker-free LED illumination, which is very comfortable for the eyes. No additional white balance is necessary.

Daylight quality, true color reproduction – 6500K color temperature allows the user to see structures in their true colors without the yellow hue of halogen illumination. Flexible controls offer quadrant selection allowing off-axis illumination by quarter segment for more detailed imaging of fine surface features. Integrated voltage controller accepts 100 VAC to 240 VAC incoming voltage. Includes AC Adapter. Lifetime warranty.
