Mitutoyo Point Micrometers - Series 342, 142, 112

Mitutoyo Point Micrometers - Series 342, 142, 112

Series 342, 142 & 112
Inch/metric Mitutoyo Point Micrometer Models include:

Mitutoyo 342-351-30

Mitutoyo 342-352-30

Mitutoyo 342-361-30

Inch Mitutoyo Point Micrometer Models include:

Mitutoyo 112-177	Mitutoyo 112-189	Mitutoyo 112-225
Mitutoyo 112-226	Mitutoyo 112-237	Mitutoyo 112-238
Mitutoyo 142-225

Metric Mitutoyo Point Micrometer Models include:

Mitutoyo 112-201

FEATURES IP65 water/dust protection (Series 342). Pointed spindle and anvil for measuring the web thickness of drills, small grooves, keyways, and other hard-to-reach dimensions. 15 degree and 30 degree measuring points are available. The measuring points have approximately 0.3mm / .012” radius. With Ratchet Stop for constant force. With SPC output (Series 342). With digit counter (Series 142). With a standard bar except 0 - 25mm and 0 - 1” model. Supplied in fitted plastic case.

IP 65 Protection Level

Level 6: Dust-proof. No ingress of dust allowed

Level 5: Protected against water jets. Water projected in jets against the enclosure from any direction shall have no harmful effects

TECHNICAL DATA

Accuracy: Refer to the list of specifications.

Resolution*: 0.001mm or .00005"/0.001mm

Graduation**: 0.01mm,.001" or .0001"

Display*: LCD

Battery*: SR44 (1 pc.), 938882

Battery life*: Approx. 1.2 years under normal use

Dust/Water protection level* IP65

*Digital models **Analog models

FUNCTION

• Origin point setting (ABS measurement system) - Resets the ABS origin at the current spindle position to the minimum value of the measuring range and switches to ABS mode.
• Zero-setting (INC measurement system) - A brief press on the ZERO/ABS button sets display to zero at the current spindle position and switches to the incremental (INC) measuring mode. A longer press resets to the ABS measuring mode
• Hold - Pressing the HOLD button freezes the current value in the display. This function is useful for preserving a measurement in situations of poor visibility where the instrument must be moved away from the workpiece before the reading can be recorded.
• Data output - Models equipped with this function have an output port for transferring measurement data to a Statistical Process Control (SPC) system. *4: Only models with the data output function
• Error alarm: - In case of an overflow on the LCD or a computing error, an error message appears on the LCD, and the measuring function stops. This prevents an instrument from giving an erroneous reading. Also, when the battery voltage drops to a certain level, the low-battery-voltage alarm annunciator appears well before the micrometer becomes unusable.
• Inch/mm conversion - for inch/metric models only

DIMENSIONS
